Apollon NC500 3 Channel Amplifier
From: 2,490.00€
The Hypex NC500 based amplifier has the option to use a custom input buffer board with class A op amps that makes the Hypex NC500 work to its fullest potential and create a mind-blowing musical experience. With our 3 Channel NC500 Amplifier you have the option to choose our custom Apollon input buffer board built around Sonic Imagery 994, Sonic Imagery 990 PRO OP Amps or Sparkos Labs SS2590 PRO op amps and Sparkos Labs regulators. The Apollon input buffer board is using highest quality 1% metal film resistors and audiophile grade polystyrene capacitors, while the power is being conditioned with discrete voltage regulators made by Sparkos Labs.
POWER RATING
WATT @ 2 OHM
WATT @ 4 OHM
WATT @ 8 OHM
SPECS
Frequency Response:
0 – 50k Hz +0/-3dB
Low Distortion:
THD+N – 0.001 % 20Hz
Signal-to-noise ratio
135db
Gain
26.5 dB Gain
Apollon Audio
binding posts
“Op Amp rolling”
Feature
The prices displayed exclude the EU VAT and will be added at checkout if you are located in the EU. All amplifiers are built to order. Estimated lead time is 14 working days for stereo amplifiers/monoblocks, 21 days for multichannel amplifiers and 30 working days for all Premium amplifiers. Please note that weekends and public holidays do not count as working days.
We ship worldwide – simply click “Add to Cart” or “Checkout with Paypal” choose your country and enter your City and valid ZIP code to calculate the shipping costs.
True Triple Mono Design
Distortion: THD+N – 0.001 % 20Hz
Frequency Response: 0 – 50k Hz +0/-3dB
High Input Impedance 47K
Signal to noise ratio: 135db
26.5 dB Gain
Ultra High Damping Factor
Power rating (channel): 550W @ 2ohm | 700W @ 4ohm | 400W @ 8ohm
Case Dimensions: 450 x 392 x 82 mm ( 104mm height with feet)
Weight: 12,7 kg
Hypex SMPS1200A700 (3 pcs.)
Hypex Ncore NC500 amplifier (3 pcs.)
Apollon Audio Input Buffer Board (3 pcs.)
High quality low voltage PSU for standby control
Neutrik gold plated XLR line input sockets (3 pcs.)
Gold plated RCA input sockets with selector switch (3 pcs. optional)
WBT 0703 CU binding posts (6 pcs.)
Neotech UP-OCC 12AWG Solid Copper Speaker output wire
12V Trigger with passthrough (optional)
High quality fused mains input socket with power ON/OFF button
Aluminium enclosure with anti-vibration aluminium feet
