PET 950 STEREO

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – 0.00035 % @ 200W, 4Ω, 1kHz
High Current Output Max 40A Capable of driving 2ohm
Power rating: 950W @ 2ohm | 500W @ 4ohm | 250W @ 8ohm

Dimensions & weight:
350mm depth x 156mm height (with feet) x 450 mm width, Weight: 19 kg
PET 950 MONOBLOCK

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – 0.00035 % @ 200W, 4Ω, 1kHz
High Current Output Max 40A Capable of driving 2ohm
Power rating: 950W @ 2ohm | 500W @ 4ohm | 250W @ 8ohm

Dimensions & weight:
350mm depth x 156mm height (with feet) x 280 mm width, Weight: 11 kg
1ET7040SA MULTICHANNEL
Pure 3-5

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – 0.00035 % @ 200W, 4Ω, 1kHz High Current Output Max 40A Capable of driving 2ohm
Power rating: 950W @ 2ohm | 500W @ 4ohm | 250W @ 8ohm

Dimensions & weight:
Pure 3-5: 390mm depth (incl. binding posts) x 95mm height (with feet) x 450 mm width, Weight: 12-14 kg
1ET7040SA MULTICHANNEL
Pure 6-12

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – 0.00035 % @ 200W, 4Ω, 1kHz High Current Output Max 40A Capable of driving 2ohm
Power rating: 950W @ 2ohm | 500W @ 4ohm | 250W @ 8ohm

Dimensions & weight:
Pure 6-12: Case Dimensions: 375mm depth x 200mm height (with feet) x 450 mm width Weight: 20-23 kg
1ET400A MULTICHANNEL
Pure 3-5

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.00017 % 20Hz-20kHz
High Current Output Max 25A
Power rating: 450W @ 2ohm | 425W @ 4ohm | 227W @ 8ohm

Dimensions & weight:
Pure 3-5: 370mm depth (incl. binding posts) x 95mm height (with feet) x 450 mm width Weight: 12-14 kg
1ET400A MULTICHANNEL
Pure 6-12

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.00017 % 20Hz-20kHz
High Current Output Max 25A
Power rating: 450W @ 2ohm | 425W @ 4ohm | 227W @ 8ohm

Dimensions & weight:
Pure 6-12: 375mm depth x 200mm height (with feet) x 450 mm width Weight: 20-23 kg
1ET7040SA STEREO AMPLIFIER

Frequency Response: 0 – 50k Hz +0/-3dB Low Distortion: THD+N – 0.00035 % @ 200W, 4Ω, 1kHz High Input Impedance 100K Signal-to-noise ratio: 129dB Gain (dB) 12,8/20,5/27,5/29 Ultra High Damping Factor High Current Output Max 40A Capable of driving 2ohm (for the Most Demanding of Speakers) Power rating: 950W @ 2ohm | 500W @ 4ohm | 250W @ 8ohm

Dimensions & weight:
Case Dimensions: 370mm depth (incl. binding posts) x 95mm height (with feet) x 450 mm width Weight: 12 kg
PNC 1200 MONOBLOCK

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.0005 % 20Hz-20kHz
High Current Output Max 40A Capable of driving 2ohm
Power rating: 1200W @ 2ohm | 700W @ 4ohm | 400W @ 8ohm

Dimensions & weight:
350mm depth x 156mm height (with feet) x 280 mm width, Weight: 11 kg
PNC2K MONOBLOCK

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.0008 % 20Hz-20kHz
High Current Output Max 48A Capable of driving 2ohm
Power rating: 2000W @ 2ohm | 2700W @ 4ohm | 1600W @ 8ohm

Dimensions & weight:
350mm depth x 205mm height (with feet) x 280 mm width Weight: 14 kg
PNC 1200 STEREO

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.0005 % 20Hz-20kHz
High Current Output Max 40A Capable of driving 2ohm
Power rating: 1200W @ 2ohm | 700W @ 4ohm | 400W @ 8ohm

Dimensions & weight:
350mm depth x 156mm height (with feet) x 450 mm width Weight: 19 kg
NC500 6-12CH

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.00080 % 20Hz-20kHz
High Current Output Max 28A
Power rating: 550W @ 2ohm | 700W @ 4ohm | 400W @ 8ohm

Dimensions & weight:
375mm depth x 200mm height (with feet) x 450 mm width Weight: 20-23 kg
1ET400A MINI

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.00017 % 20Hz-20kHz
High Current Output Max 25A
Power rating: 450W @ 2ohm | 425W @ 4ohm | 227W @ 8ohm

Dimensions & weight:
350mm depth x 90mm height (with feet) x 280 mm width, Weight: 6.8 kg

Frequency Response: 0 – 50k Hz +0/-3dB
Low Distortion: THD+N – – 0.00017 % 20Hz-20kHz
High Current Output Max 25A
Power rating: 550W @ 2ohm | 700W @ 4ohm | 400W @ 8ohm

Dimensions & weight:
350mm depth x 90mm height (with feet) x 280 mm width, Weight: 6.8 kg
