Apollon Audio NCx500 M Monoblock Amplifier
From: 890.00€
Apollon Audio Hypex
NCx500 Monoblock Amplifier
Hypex NCx500 based amplifier. Exceptional sonic performance. Lightweight Design.
The Apollon Audio NCx500 Monoblock Amplifier utilises the newest Hypex NCx500 amplifier module as its core. This exceptional technology provides abundant power and remarkable precision, making it an ideal choice for discerning audiophiles and professional studio applications. With unparalleled clarity and a candid, linear sound, the Apollon NCx500 delivers exceptional performance for even the most demanding speakers.

Ultra Low Distortion
The Apollon Audio NCx500 mono amplifier delivers exceptional performance with its ultra low distortion (THD+N – 0.0002 %) as a result of the Hypex NCx500 amplifier module combined with our custom input buffer boards.

Balanced & Single-ended Input
with Gain Selection
The signal to the amplifier can be provided by using XLR balanced or RCA single-ended cables. The custom input buffer board offers 4 different input gain settings levels.

"Op Amp rolling" Feature
Our custom input buffer board by default comes with the very advanced OPA 1656 operational amplifiers. But if you would at any time wish to change the sound characteristics of the Apollon NCx500 amplifier you can do so with simply exchanging the op amp (so called Op amp rolling). Our custom input buffer board comes with a DIP8 socket that enables you to attach a wide range of DIP8 compatible operational amplifiers on the market.

Don't miss out on the chance to acquire the exceptional Hypex NCx500 monoblock amplifier crafted with top quality components to deliver the incredible audio performance you've always desired. Finally get the amazing sound that you have dreamed about, for just a fraction of the cost.
The prices displayed exclude the EU VAT and will be added at checkout if you are located in the EU. Estimated lead time is 14 working days for stereo amplifiers/monoblocks.
We ship worldwide – simply click “Add to Cart” or “Checkout with Paypal” choose your country and enter your City and valid ZIP code to calculate the shipping costs.
Order Now!
Select your desired color and simply click add to cart.
HYPEX NCX500 BASED MONOBLOCK AMPLIFIER
ELEGANT AND WITH A SIMPLY PURE SOUND
Compact stereo amplifier with exceptionally detailed sound in a small and light weight form factor. The enclosure is made of aluminium and has an anodised finish.
The Apollon Audio NCX500 M Monoblock Amplifier is built around the new amazing Hypex NCX500 amplifier module in a very compact and lightweight design with amazing clarity and brutally honest linear sound.
SPACIOUS, AIRY SOUND, ABUNDANT IN VIVID DETAIL WITH OUR CUSTOM INPUT BUFFER BOARD WITH OPA1612 OP AMPS
The Apollon Audio NCX500 M Monoblock Amplifier is exceptionally fast, uncommonly clean, and musical with a lot of detail. It comes standard with 4 selectable gain settings, switchable input between Neutrik XLR balanced / Gold plated single-ended inputs, 12V trigger with passthrough and Furutech FI-06 gold-plated mains input.
POWER RATING
WATT @ 2 OHM
WATT @ 4 OHM
WATT @ 8 OHM
SPECS
Frequency Response:
0 – 70k Hz +0/-3dB
Low Distortion:
THD+N – – 0.0002 % 20Hz-20kHz
Signal-to-noise ratio
137db
Gain
12,8/20,5/27,5/29 dB Gain
Apollon Audio
binding posts

The prices displayed exclude the EU VAT and will be added at checkout if you are located in the EU. All amplifiers are built to order.
We ship worldwide – simply click “Add to Cart” or “Checkout with Paypal” choose your country and enter your City and valid ZIP code to calculate the shipping costs.
– Balanced XLR input connector
– Unbalanced RCA input connector
– Selectable input sensitivity gain switch
– Pure OFC copper binding posts
– Furutech mains inlet
– 12V trigger input with passthrough
– Dimmable LED front light
– OP amp rolling (DIP-8 socket)
Frequency Response: 0 – 70k Hz +0/-3dB
Low Distortion: THD+N – – 0.0002 % 20Hz-20kHz
High Input Impedance 50K
Signal to noise ratio: 137dB
Gain (dB) 12,8/20,5/27,5/29
Ultra High Damping Factor
High Current Output
Power rating: 700W @ 2ohm | 700W @ 4ohm | 380W @ 8ohm
Case Dimensions: 305mm depth x 69mm height (with feet) x 250 mm width
Weight: 2.9 kg
Hypex SMPS1200A700 (1 pcs.)
Hypex NCX500 amplifier (1 pcs.)
Apollon Audio Input Buffer Board (1 pcs.)
Apollon Control Board for standby control
Neutrik silver plated XLR line input socket (1 pcs.)
Gold plated RCA input with selector switch
Apollon OFC binding posts (2 pcs.)
Neotech UP-OCC 12AWG Solid Copper and
12V Trigger for wakeup from standby
High quality Furutech FI-06 mains input socket
Aluminium enclosure with anti-vibration rubber feet
